Động cơ Servo Yaskawa SGM7A
2/11/2021
Động cơ Servo Yaskawa SGM7A
Video
Flyer Brochure Tech Supplement
Core Manuals Configurator Instructions
Động cơ Servo Yaskawa SGM7A
Động cơ Servo Yaskawa SGM7A 200V Input (24-bit encoder)
|
Rated Output
|
Options
|
|
|---|---|---|
| SGM7A-A5A7D61 | 50W | No Options |
| SGM7A-A5A7D6C | 50W | 24V Brake |
| SGM7A-A5A7D6E | 50W | 24V Brake, Shaft Seal |
| SGM7A-A5A7D6S | 50W | Shaft Seal |
| SGM7A-01A7D61 | 100W | No Options |
| SGM7A-01A7D6C | 100W | 24V Brake |
| SGM7A-01A7D6E | 100W | 24V Brake, Shaft Seal |
| SGM7A-01A7D6S | 100W | Shaft Seal |
| SGM7A-C2A7D61 | 150W | No Options |
| SGM7A-C2A7D6C | 150W | 24V Brake |
| SGM7A-C2A7D6E | 150W | 24V Brake, Shaft Seal |
| SGM7A-C2A7D6S | 150W | Shaft Seal |
| SGM7A-02A7D61 | 200W | No Options |
| SGM7A-02A7D6C | 200W | 24V Brake |
| SGM7A-02A7D6E | 200W | 24V Brake, Shaft Seal |
| SGM7A-02A7D6S | 200W | Shaft Seal |
| SGM7A-04A7D61 | 400W | No Options |
| SGM7A-04A7D6C | 400W | 24V Brake |
| SGM7A-04A7D6E | 400W | 24V Brake, Shaft Seal |
| SGM7A-04A7D6S | 400W | Shaft Seal |
| SGM7A-06A7D61 | 600W | No Options |
| SGM7A-06A7D61 | 600W | 24V Brake |
| SGM7A-06A7D61 | 600W | 24V Brake, Shaft Seal |
| SGM7A-06A7D61 | 600W | Shaft Seal |
| SGM7A-08A7D61 | 750W | No Options |
| SGM7A-08A7D6C | 750W | 24V Brake |
| SGM7A-08A7D6E | 750W | 24V Brake, Shaft Seal |
| SGM7A-08A7D6S | 750W | Shaft Seal |
| SGM7A-10A7D61 | 1.0kW | No Options |
| SGM7A-10A7D6C | 1.0kW | 24V Brake |
| SGM7A-10A7D6E | 1.0kW | 24V Brake, Shaft Seal |
| SGM7A-10A7D6S | 1.0kW | Shaft Seal |
| SGM7A-15A7D61 | 1.5kW | No Options |
| SGM7A-15A7D6C | 1.5kW | 24V Brake |
| SGM7A-15A7D6E | 1.5kW | 24V Brake, Shaft Seal |
| SGM7A-15A7D6S | 1.5kW | Shaft Seal |
| SGM7A-20A7D61 | 2.0kW | No Options |
| SGM7A-20A7D6C | 2.0kW | 24V Brake |
| SGM7A-20A7D6E | 2.0kW | 24V Brake, Shaft Seal |
| SGM7A-20A7D6S | 2.0kW | Shaft Seal |
| SGM7A-25A7D61 | 2.5kW | No Options |
| SGM7A-25A7D6C | 2.5kW | 24V Brake |
| SGM7A-25A7D6E | 2.5kW | 24V Brake, Shaft Seal |
| SGM7A-25A7D6S | 2.5kW | Shaft Seal |
| SGM7A-30A7D61 | 3.0kW | No Options |
| SGM7A-30A7D6C | 3.0kW | 24V Brake |
| SGM7A-30A7D6E | 3.0kW | 24V Brake, Shaft Seal |
| SGM7A-30A7D6S | 3.0kW | Shaft Seal |
| SGM7A-40A7D61 | 4.0kW | No Options |
| SGM7A-40A7D6C | 4.0kW | 24V Brake |
| SGM7A-40A7D6E | 4.0kW | 24V Brake, Shaft Seal |
| SGM7A-40A7D6S | 4.0kW | Shaft Seal |
| SGM7A-50A7D61 | 5.0kW | No Options |
| SGM7A-50A7D6C | 5.0kW | 24V Brake |
| SGM7A-50A7D6E | 5.0kW | 24V Brake, Shaft Seal |
| SGM7A-50A7D6S | 5.0kW | Shaft Seal |
| SGM7A-70A7D6S | 7.0kW | No Options |
Động cơ Servo Yaskawa SGM7A 400V Input (24-bit encoder)
|
Rated Output
|
Options
|
|
|---|---|---|
| SGM7A-02D7F61 | 200W | No Options |
| SGM7A-02D7F6C | 200W | 24V Brake |
| SGM7A-02D7F6E | 200W | 24V Brake, Shaft Seal |
| SGM7A-02D7F6S | 200W | Shaft Seal |
| SGM7A-04D7F61 | 400W | No Options |
| SGM7A-04D7F6C | 400W | 24V Brake |
| SGM7A-04D7F6E | 400W | 24V Brake, Shaft Seal |
| SGM7A-04D7F6S | 400W | Shaft Seal |
| SGM7A-08D7F61 | 750W | No Options |
| SGM7A-08D7F6C | 750W | 24V Brake |
| SGM7A-08D7F6E | 750W | 24V Brake, Shaft Seal |
| SGM7A-08D7F6S | 750W | Shaft Seal |
| SGM7A-10D7F61 | 1.0kW | No Options |
| SGM7A-10D7F6C | 1.0kW | 24V Brake |
| SGM7A-10D7F6E | 1.0kW | 24V Brake, Shaft Seal |
| SGM7A-10D7F6S | 1.0kW | Shaft Seal |
| SGM7A-15D7F61 | 1.5kW | No Options |
| SGM7A-15D7F6C | 1.5kW | 24V Brake |
| SGM7A-15D7F6E | 1.5kW | 24V Brake, Shaft Seal |
| SGM7A-15D7F6S | 1.5kW | Shaft Seal |
| SGM7A-20D7F61 | 2.0kW | No Options |
| SGM7A-20D7F6C | 2.0kW | 24V Brake |
| SGM7A-20D7F6E | 2.0kW | 24V Brake, Shaft Seal |
| SGM7A-20D7F6S | 2.0kW | Shaft Seal |
| SGM7A-25D7F61 | 2.5kW | No Options |
| SGM7A-25D7F6C | 2.5kW | 24V Brake |
| SGM7A-25D7F6E | 2.5kW | 24V Brake, Shaft Seal |
| SGM7A-25D7F6S | 2.5kW | Shaft Seal |
| SGM7A-30D7F61 | 3.0kW | No Options |
| SGM7A-30D7F6C | 3.0kW | 24V Brake |
| SGM7A-30D7F6E | 3.0kW | 24V Brake, Shaft Seal |
| SGM7A-30D7F6S | 3.0kW | Shaft Seal |
| SGM7A-40D7F61 | 4Kw | No Options |
| SGM7A-40D7F6C | 4kW | 24V Brake |
| SGM7A-40D7F6E | 4kW | 24V Brake, Shaft Seal |
| SGM7A-40D7F6S | 4kW | Shaft Seal |
| SGM7A-50D7F61 | 5kW | No Options |
| SGM7A-50D7F6C | 5kW | 24V Brake |
| SGM7A-50D7F6E | 5kW | 24V Brake, Shaft Seal |
| SGM7A-50D7F6S | 5kW | Shaft Seal |
