Servo Mitsubishi MR-JET Series

Liên hệ báo giá

Servo Mitsubishi MR-JET Series Servo Mitsubishi MR-JET Series MR-JET Series MODEL NAME FILE INFORMATION DOWNLOAD FILE SIZE (BYTES) MR-JET-10G MR-JET-20G MR-JET-40G 2D jet-10g_a_dxf.zip 70,871 2D jet-10g_a_dwg.zip 79,457 3D jet-10g_a_igs.zip 135,869 3D jet-10g_a_stp.zip 86,288 MR-JET-70G MR-JET-100G

Đặt hàng & tư vấn kỹ thuật

Hotline: 0904.918.479 Hotline: 0981.808.969 Hotline: 0963.600.499 Email: hungpv@haphongjsc.com

Gọi báo giá ngay Gửi yêu cầu

Thông tin chi tiết

Servo Mitsubishi MR-JET Series

MR-JET Series

MODEL NAME	FILE INFORMATION	DOWNLOAD FILE	SIZE (BYTES)
MR-JET-10G MR-JET-20G MR-JET-40G	2D	jet-10g_a_dxf.zip	70,871
	2D	jet-10g_a_dwg.zip	79,457
	3D	jet-10g_a_igs.zip	135,869
	3D	jet-10g_a_stp.zip	86,288
MR-JET-70G MR-JET-100G	2D	jet-70g_a_dxf.zip	87,840
	2D	jet-70g_a_dwg.zip	94,450
	3D	jet-70g_a_igs.zip	145,955
	3D	jet-70g_a_stp.zip	92,133
MR-JET-200G MR-JET-300G	2D	jet-200g_a_dxf.zip	63,093
	2D	jet-200g_a_dwg.zip	71,166
	3D	jet-200g_a_igs.zip	148,760
	3D	jet-200g_a_stp.zip	90,253

[Copyright]

Mitsubishi Electric Corporation

Servo Mitsubishi

(1) CAD data file formats

FORMAT	EXTENSION	CAD SOFTWARE	COMPANY
DXF	.dxf	Auto CAD LT2000 Auto CAD 2000	Autodesk Inc.
DWG	.dwg	Auto CAD LT2000 Auto CAD 2000	Autodesk Inc.

Decompress and use the downloaded compressed file.
Import the data into your CAD software.
Mitsubishi Electric has confirmed that the above CAD software applications will read DXF and DWG files.

(2) Important

– Because DXF files are intermediate files, the data is not fully compatible. Some CAD software may not read the files completely.
– These DXF and DWG files were created using millimeters as the unit. Dimensions indicated are valid to 2 decimal places.
– DXF and DWG data is the format for Auto CAD Release 14J, Auto CAD LT98 and Auto CAD LT97. However, where the file name ends with “*2”, the format is for Auto CAD 2000 and Auto CAD LT2000.

By downloading 2D-CAD data or 3D-CAD data, you consent to the terms given above.
